Practical ETABS Training of G+9 Building with RSA Analysis

Analysis & Design of G+9 Residential building with Static & Dynamic Response Spectrum Analysis method in Practical way.
4.33 (3 reviews)
Udemy
platform
English
language
Other
category
instructor
Practical ETABS Training of G+9 Building with RSA Analysis
39
students
28.5 hours
content
Sep 2022
last update
$19.99
regular price

Why take this course?

🚀 Course Title: Practical ETABS Training of G+9 Building with RSA Analysis 🏢


About Gururayar Associates 🌍

GURURAYAR ASSOCIATES is a ISO 9001-2015 certified engineering consultancy and training institute, registered under MSME with a rich history of 25 years in the realm of industrial, commercial, and residential design. Our mission is to cultivate independent professional structural design engineers across India and abroad, empowering them with our practical design methodology that's currently shaping the industry. We are dedicated to delivering top-quality and economic structural design services to our clients, always striving for excellence.

Our Mission:

"To build an independent professional structural design engineers/consultants in all over India and abroad as well."

Our Vision:

"To give real service, you must add something which cannot be bought or measured by MONEY" - Sir M.Vishveshwarayya.

Our Motto:

HELP EACH OTHER! GROW TOGETHER!!! 🚀


Course Description: 🎓

Embark on a comprehensive learning journey with our Practical ETABS Training of G+9 Building with RSA Analysis course. This course is meticulously designed to take you through the intricacies of modeling, analysis, and design using ETABS software for a G+9 residential building. From understanding the basics of structural modeling to mastering the Response Spectrum Analysis (RSA) method for dynamic response, this course covers everything you need to know.

What You Will Learn:

  1. Structural Modeling in ETABS:

    • Draw beams, columns, and slabs with different methods.
    • Assign properties to frame and area elements accurately.
    • Set up constraints and support conditions effectively.
  2. Assign Restraints and Load Cases:

    • Apply fixed, pinned, or roller supports at joints as required.
    • Define and assign various load cases including dead load, live load, wind load, and seismic load.
  3. Material Properties and Concrete/Steel Frame Design:

    • Specify material properties for both concrete and steel frames.
    • Perform design checks for frames and view design results.
    • Analyze the structural adequacy and optimize the design parameters.
  4. Response Spectrum Analysis & Design:

    • Understand and apply RSA functions manually or automatically.
    • Calculate sa/g acceleration values and create dynamic loads.
    • Perform RSA analysis and interpret results for story deflections, drifts, and torsional effects.
    • Insert shear walls or bracings to correct any structural inadequacies identified during RSA.
  5. Dynamic Modal Cases and Scale Factor Corrections:

    • Create and analyze dynamic modal cases for the building structure.
    • Adjust base reactions by applying scale factor corrections if necessary.

Course Syllabus: 📚

Structural Modeling in ETABS:

  • Drawing beams, columns, and slabs with various methods.
  • Assigning properties to frame and area elements.
  • Setting up constraints and support conditions for accurate analysis.

Assign Restraints and Load Cases:

  • Applying fixed, pinned, or roller supports at joints.
  • Defining and assigning dead load, live load, wind load, and seismic load cases.

Material Properties and Concrete/Steel Frame Design:

  • Specifying material properties for concrete and steel frames.
  • Performing design checks for frames and viewing design results.
  • Analyzing and optimizing the structural adequacy of frames.

Response Spectrum Analysis & Design:

  • Understanding RSA functions and manual calculations of sa/g acceleration values.
  • Creating dynamic loads and performing modal analysis.
  • Interpreting RSA analysis results for story deflections, drifts, and torsional effects.
  • Inserting shear walls or bracings to enhance structural stability.

Join us on this enlightening path to master ETABS and excel in the field of structural engineering. With our expert instructors and hands-on approach, you'll gain the skills and knowledge necessary to tackle complex projects with confidence. 🛠️💡

Enroll now and transform your career in structural design! 🌟

Course Gallery

Practical ETABS Training of G+9 Building with RSA Analysis – Screenshot 1
Screenshot 1Practical ETABS Training of G+9 Building with RSA Analysis
Practical ETABS Training of G+9 Building with RSA Analysis – Screenshot 2
Screenshot 2Practical ETABS Training of G+9 Building with RSA Analysis
Practical ETABS Training of G+9 Building with RSA Analysis – Screenshot 3
Screenshot 3Practical ETABS Training of G+9 Building with RSA Analysis
Practical ETABS Training of G+9 Building with RSA Analysis – Screenshot 4
Screenshot 4Practical ETABS Training of G+9 Building with RSA Analysis
