Mastering Electrical Transformers
Theory, Construction, types and Testing of transformers
5.00 (5 reviews)
105
students
4 hours
content
Jun 2025
last update
$19.99
regular price
What you will learn
Working principle of transformer, Importance , advantages, limitations and applications of transformer
Construction of Transformer: Core, Windings, Insulation, Cooling System, Transformer Tank, Conservator Tank, Breather Unit, Buchholz Relay, Explosion Vent
Classification of Transformer: Core type and Shell type of Transformer, Power Transformer, Distribution Transformer, Instrument Transformer , Current Transform
Classification of Transformer: Potential Transformer (PT), Auto Transformer, Three-Phase Transformer, Ideal transformer, Isolation Transformer
Transformer losses: Copper Losses, Core Losses, Hysteresis and Eddy Current Losses, Stray Losses, Dielectric Losses
Transformer Testing: Open circuit test, Short Circuit test, Oil Breakdown Voltage (BDV) Test, Dissolved Gas Analysis (DGA)
Transformer Testing: Partial Discharge (PD) Testing, Dielectric Loss Test, High Potential (Hipot) Test, Insulation Resistance - IR Test, Polarity Test
Transformer Testing: Winding Resistance Testing, Vector Group Testing, Transformer Turns Ratio (TTR) Test, Acidity Test, Furan Testing
Miscellaneous: Practice sets, Earthing, Harmonics, Transformer Maintenance Checklist
