Advanced PCB Design with KiCad 9
From Concept to Manufacturing: Build, Test, and Deliver a Four-Layer IoT PCB Using KiCad 9
4.71 (34 reviews)
656
students
8 hours
content
Apr 2025
last update
$44.99
regular price
What you will learn
Design a complete four-layer PCB with KiCad 9.
Create schematics, assign footprints, and route tracks for high-speed signals like SPI, I2C, and USB.
Implement power and ground planes, copper zones, and via stitching for signal integrity.
Troubleshoot and resolve design issues using KiCad's Electrical Rules Check (ERC) and Design Rules Check (DRC).
Run Design for Manufacturing (DFM) checks with NextPCB to ensure production-ready designs.
Test and validate key PCB components such as an SD card interface, flash memory, sensors, microphone, and OLED display.
Analyze analog and digital signals using test scripts, an oscilloscope, and KiCad's simulation tools.
Techniques for ensuring signal integrity through proper ground and power plane design.
Methods to debug and resolve common PCB design issues using KiCad's tools.
The process for preparing PCB designs for manufacturing with NextPCB or other manufacturers.
Practical skills for testing and validating PCB functionality using an oscilloscope and multimeter.
Insights into the challenges and best practices of IoT PCB design.
